10 CC-Link Code Numbers
28
◆ Extended Command Codes
Table 19 Extended Command Codes
Command Code Name
Read Write BIT
100H
<1> See Fault Contents on page 30 for information on fault contents.
–
Operation signals
0
H5-12 = 0: Forward run command (0 = Stop, 1 = Forward run)
H5-12 = 1: Run command (0 = Stop, 1 = Run)
1
H5-12 = 0: Reverse run command (0 = Stop, 1 = Reverse run)
H5-12 = 1: Forward/Reverse (0 = Forward, 1 = Reverse)
2 External fault (EF0)
3 Fault reset
4
Multi-function input 1
Bit disabled when H1-01 = 40 (FWD/Stop)
5
Multi-function input 2
Bit disabled when H1-02 = 41 (REV/Stop)
6 Multi-function input 3
7 Multi-function input 4
8 Multi-function input 5
9 Multi-function input 6
A Multi-function input 7
B to F Reserved
101H – Frequency reference (RAM)
102H 202H Torque reference / torque limit
103H 203H Torque compensation
104H 204H PID setpoint
105H 205H Analog output terminal AM
107H 207H Multi-function relay output
109H 209H Pulse output
110H –
Status signal
0 During run
1 During zero speed
2 During reverse
3 During fault reset signal input
4 During speed agree
5 Drive Ready
6Alarm
7Fault
8 During operation error (oPE)
9 During Momentary power loss
A NetCtrl status
B Multi-function contact output (terminal MA/MB-MC)
C Multi-function photocoupler output 1 (terminal P1 - PC)
D Multi-function photocoupler output 2 (terminal P2 - PC)
E Motor 2 selected
F Reserved
111H – Speed restore
112H – Through-mode
114H – Frequency reference
115H – Output frequency
116H – Output current
117H – Analog input terminal A1
118H – DC bus voltage
11CH – Analog input terminal A2
11DH – Sequence input
120H – Fault contents 1
<1>
121H – Fault contents 2 <1>
122H – Fault contents 3 <1>
123H – Fault contents 4 <1>
124H – Fault contents 5 <1>
130H – CPF contents 1 <1>
131H – CPF contents 2 <1>
