Sumitomo HF-520 - Monitor Code Table

10 CC-Link Code Numbers
29
◆ Monitor Codes
Table 20 Monitor Codes
Monitor Code Name Comments
0000H Reserved
0001H Output frequency Units are determined by o1-03.
0002H Output current Units are either 0.1 A or 0.01 A, depending on the capacity of the drive.
0003H Output voltage reference Units: 0.1 V
0004H Reserved
0005H Frequency reference Units are determined by o1-03.
0006H Motor speed
Units: 1 min
-1
0007H Motor torque Units: 0.1%
0008H DC bus voltage Units: 1 V
0009H Reserved
000AH Reserved
000BH Reserved
000CH Reserved
000DH Reserved
000EH Output power Units: 0.1 kW
000FH Input terminal status
0010H Output terminal status
0011H Reserved
0012H Motor excitation current Units: 0.1%
0013H Reserved
0014H Cumulative operation time
• Units: 1 hour
• Parameter o4-02 determines if the operation time is the considered to be whenever the drive powered on or
only when there is voltage output.
0015H Reserved
0016H Reserved
0017H Actual operation time
• Units: 1 hour
• Parameter o4-02 determines if the operation time is the considered to be whenever the drive powered on or
only when there is voltage output.
0018H Motor secondary current
0019H Reserved
0034H PID setpoint Units: 0.1%
0035H PID input Units: 0.1%
0036H PID output Units: 0.1%
1000H Reserved
1001H Reserved
1002H Cumulative operation time
1003H Watt-hour output (lower digits)
1004H Watt-hour output (upper digits)
1010H Alarm code
1011H Fault code
1012H Reserved
1013H Fault contents 1
<1>
1014H Fault contents 2 <1>
1015H Fault contents 3 <1>
1016H Fault contents 4 <1>
1017H
Fault contents 5
<1>
76543210
Multi-Function Digital Input 1 (terminal S1 enabled)
Multi-Function Digital Input 2 (terminal S2 enabled)
Multi-Function Digital Input 3 (terminal S3 enabled)
Multi-Function Digital Input 4 (terminal S4 enabled)
Multi-Function Digital Input 5 (terminal S5 enabled)
Multi-Function Digital Input 6 (terminal S6 enabled)
Multi-Function Digital Input 7 (terminal S7 enabled)
Not used
1: ONRW 0: OFF
76543210
Multi-Function Digital Output (terminal MA/MB-MC) enabled
Multi-Function Digital Output 1 (terminal P1) enabled
Multi-Function Digital Output 2 (terminal P2) enabled
1: ONRW 0: OFF
Not used
