INSTRUCTION MANUAL
Please read the following instructions and warnings carefully
before set up and use.
Weight:
Height:
REAR-FACING INFANT CAR SEAT
BASE REMOVAL WITH LATCH
(LOWER ANCHORS) (CONT.)
14
15
15
Squeeze the clip then push the hook towards the seat, lift or twist hook out from the
vehicle LATCH anchor. You may need to further loosen the tension on the LATCH strap
by pushing the LATCH strap adjustment button and pulling on the strap. Repeat on other
side of base.
When storing, place the LATCH strap and hooks inside the LATCH storage.
Insert the straps on either side of the storage area in the designated slots.
NEVER allow straps to lie outside the storage area when LATCH is not in use as it may
interfere with the carrier latching to the base.
Slot
location
Slot
location
1
2
14
