77
CHECKING THE RECLINE WITH THE BASE
To Adjust Recline Angle
Pull up the recline adjustment lever
while holding the front of base. Extend or
retract the recline foot until blue square
is fully visible in the level indicator
window. IF BLUE SQUARE IS NOT FULLY
VISIBLE IN WINDOW, BASE IS NOT
LEVEL.
Release handle to lock foot into one of
the 4 recline positions.
Install Base. Be sure to check for correct
recline angle after installation.
If the recline angle is not correct after
installation,uninstall the base, adjust
recline foot and re-install.
There are four recline positions:
LEVEL Indicator
D0000000375 8/19
Indicador del NIVEL
LEVEL when blue is fully visible in window.
LEVEL when blue is fully visible in window.
1
1
2
2
