Summer AFFIRM 335 - Vehicle Belt Installation

58
BASE INSTALLATION WITH VEHICLE LAP/SHOULDER BELT
BEFORE installing base, make
sure vehicle is on level ground.
Place base on an approved vehicle
seating location. Make sure the
LATCH straps are stored in the
storage area.
Position base on the rear vehicle
seat so that it touches the vehicle
seat back.
Adjust the recline foot to get the
correct recline angle, see pg. 77.
Rotate handle on base to open the
Belt Tensioning Arm.
2
Max. 1”(2.54cm)
1
2
1
2
