Sun Microsystems GDM-5510 Service Manual

GDM-5510 (E) 6-18
No. # Board Type ! / * Ref. No. Part No. Description Remarks-1 Remarks-2 Difference
545 D DIODE D921 8-719-911-19 DIODE 1SS119-25
546 D DIODE D922 8-719-404-50 DIODE MA111-TX
547 D DIODE D923 8-719-404-50 DIODE MA111-TX
548 D FUSE ! F601 1-576-233-11 FUSE (H.B.C.) (6.3A/250V)
549 D FERRITE BEAD FB501 1-410-397-21 FERRITE 1.1uH
550 D CHIP CONDUCTOR FB555 1-216-295-91 SHORT 0
551 D FERRITE BEAD FB901 1-412-911-11 FERRITE 1.1uH
552 D FERRITE BEAD FB902 1-414-231-22 FERRITE 0uH
553 N FERRITE BEAD FB1000 1-414-231-22 FERRITE 0uH
554 N CHIP CONDUCTOR FB1002 1-216-295-91 SHORT 0
555 N CHIP CONDUCTOR FB1005 1-216-295-91 SHORT 0
556 N CHIP CONDUCTOR FB1007 1-216-295-91 SHORT 0
557 D FUSE HOLDER FH601 1-533-223-11 HOLDER, FUSE
558 D FUSE HOLDER FH602 1-533-223-11 HOLDER, FUSE
559 D IC IC401 8-759-192-71 IC STV9379
560 D IC IC501 8-759-585-82 IC BA9759F-E2
561 D IC IC610 8-749-018-08 IC MZ1532
562 D IC IC620 8-759-670-30 IC MCZ3001D
563 D IC IC630 8-759-535-32 IC FA13842P
564 D IC IC640 8-749-018-07 IC SEB3-LF4
565 D IC IC652 8-759-669-10 IC BA3953T-V5
566 D IC IC654 8-759-701-79 IC NJM7812FA
567 D IC IC680 8-759-682-42 IC MM1431ATT
568 D IC IC701 8-759-822-38 IC LA6510
569 D IC IC702 8-749-017-48 IC STK391-220
570 D RTV * IC703 7-322-065-48 RUBBER, SILICONE RTV (KE-3490)
571 D IC IC703 8-759-803-42 IC LA6500-FA
572 D IC IC901 8-759-585-81 IC BA9758FS-E2
573 D IC IC902 8-759-701-01 IC NJM2904M
574 D CHIP CONDUCTOR JR001 1-216-295-91 SHORT 0
575 D CHIP CONDUCTOR JR002 1-216-296-11 SHORT 0
576 D CHIP CONDUCTOR JR003 1-216-296-11 SHORT 0
577 D CHIP CONDUCTOR JR004 1-216-296-11 SHORT 0
578 D CHIP CONDUCTOR JR006 1-216-296-11 SHORT 0
