Appendix A Mapping Device Path Names 101
I/O Device Mapping on Entry-Level Servers
TABLE A-3 shows the device mapping on an entry-level server.
Internal Devices on Entry-Level Servers
The entry-level server has a single system board, at location XSB 00-0. Internal
devices and device paths are shown in
TABLE A-4.
TABLE A-3 I/O Device Mapping on an Entry-level Server
PCIe Slot Host Bus Adapter Slot Type OpenBoot PROM Device Path
Slot 0 PCIe /pci@0,600000/pci@0/pci@8
Slot 1 PCIe /pci@1,700000/pci@0/pci@0
Slot 2 PCIe /pci@1,700000/pci@0/pci@8
Slot 3 PCIe /pci@1,700000/pci@0/pci@9
TABLE A-4 Internal Devices and Device Paths on an Entry-level Server
XSB 00-0/IOU 0
Accessible Internal
Devices
Device Physical
Location OpenBoot PROM Device Path
Network Port 0 System /pci@0,600000/pci@0/pci@1/pci@0/network@4
Network Port 1 System /pci@0,600000/pci@0/pci@1/pci@0/network@4,1
Network Port 2 System /pci@0,600000/pci@0/pci@2/pci@0/network@4
Network Port 3 System /pci@0,600000/pci@0/pci@2/pci@0/network@4,1
HD0 System /pci@0,600000/pci@0/pci@0/scsi@0/disk@0
HD1 System /pci@0,600000/pci@0/pci@0/scsi@0/disk@1
HD2 System /pci@0,600000/pci@0/pci@0/scsi@0/disk@2
HD3 System /pci@0,600000/pci@0/pci@0/scsi@0/disk@3
CD-RW/DVD-RW System /pci@0,600000/pci@0/pci@0/scsi@0/disk@4
SAS port System /pci@0,600000/pci@0/pci@0/scsi@0/xx@5,z, where xx the disk when
connecting to a disk, or a tape when connecting to a tape drive unit.
