104 SPARC Enterprise Mx000 Servers Administration Guide • August 2009
to storage located on the IOU, as well as platform CD-RW/DVD-RW drive or tape
drive resources at the locations shown in
TABLE A-9. In the PCIe device path, x is LSB-
dependent, and is assigned a value as shown in
TABLE A-2. xx is the XSB number and
is in the range from 00-15. nn is the number associated with the PSB to which the CD-
RW/DVD-RW drive or tape drive is attached, as further explained in the table
footnote.
TABLE A-9 Internal Devices and Device Paths on a High-end Server
PCIe Slot
Uni-
XSB
*
Quad-
XSB
†
OpenBoot PROM
PCIe Device
Path
‡
OpenBoot PROM IOUA HBA On-board, IOU, and Platform Accessible
Devices
**
IOU Slot 0 xx-0 xx-0 pci@x0,600000 .../pci@0,1/network@1 (IOUA HBA On-board BGE Port 0)
.../pci@0,1/network@1,1 (IOUA HBA On-board BGE Port 1)
.../pci@0/scsi@1/disk@0 (IOU HD0; SCSI Target 0)
.../pci@0/scsi@1/disk@1 (IOU HD1; SCSI Target 1)
.../pci@0/scsi@1/disk@4 (Platform CD-RW/DVD-RW at
cfgdevice port
nn-0; SCSI Target 4)
.../pci@0/scsi@1/tape@5 (Platform tape at cfgdevice port nn-0;
SCSI Target 5)
IOU Slot 1 xx-0 xx-0 pci@
x1,700000
IOU Slot 2 xx-0 xx-1 pci@
x2,600000 .../pci@0,1/network@1 (IOUA HBA On-board BGE Port 0)
.../pci@0,1/network@1,1 (IOUA HBA On-board BGE Port 1)
.../pci@0/scsi@1/disk@4 (Platform CD-RW/DVD-RW at
cfgdevice port
nn-2; SCSI Target 4)
.../pci@0/scsi@1/tape@5 (Platform tape at cfgdevice port nn-2;
SCSI Target 5)
IOU Slot 3 xx-0 xx-1 pci@
x3,700000 .
IOU Slot 4 xx-0 xx-2 pci@
x4,600000 .../pci@0,1/network@1 (IOUA HBA On-board BGE Port 0)
.../pci@0,1/network@1,1 (IOUA HBA On-board BGE Port 1)
.../pci@0/scsi@1/disk@0 (IOU HD2; SCSI Target 0)
.../pci@0/scsi@1/disk@1 (IOU HD3; SCSI Target 1)
.../pci@0/scsi@1/disk@4 (Platform CD-RW/DVD-RW at
cfgdevice port
nn-4; SCSI Target 4)
.../pci@0/scsi@1/tape@5 (Platform tape at cfgdevice port nn-4;
SCSI Target 5)
