7. Use a 7/16” wrench or driver to remove the bolts at one side of the dome face and use them
to loosely attach the dome guard to the front of the unit. Repeat this process to attach the other side of
the guard, then tighten the fasteners on both sides.
TO ASSEMBLE THE UNIT (CONT.):
ATTACH GUARD: DETAIL
ATTACH GUARD: LOCATIONS
ADJUST FEETUPRIGHT THE HEATER
6. Carefully, right the unit onto its lower support frame and wheels by rolling it sideways. Do not lay the
heater on the dome face at any time. Check the stability of the heater as it sits on a level floor. If the
heater rocks or is otherwise unstable, rotate the leveling feet to stabilize the heater. When the heater is
stable, use the angled wrench included in the packaging to tighten the locking nut of the leveling feet to
the foot-assembly frame, securing the leveling-feet adjustment setting.
