Sungrow COM100E - Appendix; 10.1 Technical Parameters

34
10 Appendix
10.1 Technical Parameters
Communication
No. of supportable
device
30 at most
RS485 interface
3
Ethernet port
1, 10/100/1000Mbps self-adaptive
Digital input port
5
Analog input port
4, support of 4～20mA or 0～10Vdc
Wireless communication
Operator
Support of China Mobile/China Unicom/China Telecom,
4G/3G/2G
4G frequency
band
LTE(FDD): B1, B3, B5, B8
LTE(TDD): B38, B39, B40, B41
TD-SCDMA: B34, B39
CDMA: BC0
GSM: 900 MHz /1800 MHz
WCDMA: B1,B8
WiFi
communication
802.11 b/g/n/ac; HT20/40/80MHz; 2.4GHz/5GHz
Power supply
AC input
100 Vac ~ 277 Vac, 50/60 Hz
Power
consumption
Avg. 20W; Max. 30W
Lighting device
<1 W
Ambient parameter
Operating
temperature
-30℃ ~ +60℃
Storage
temperature
-40℃ ~ +85℃
Operating humidity
≤95% (no condensation)
Operating altitude
≤4000m
Ingress of
protection
IP66
Mechanical parameters
Dimensions (W x
H x D)
460 mm x 315 mm x 130 mm
Weight
6 kg
Installation
Bracket-mounting, wall-mounting, or pole-mounting
