3 Electrical Connection
Medium-voltage connections should only be made by a qualified person who is
authorized to make medium voltage connections.
Perform cable connections in strict accordance with the terminal phase sequence.
This chapter mainly describes the locations of cable connection terminals and
recommended cable specifications.
3.1 Connection Area
MVT of SG4400UD-MV-US as reference， connection area for the medium-voltage elbow
connectors and the cables are shown in the following figure.
Dimensions of the cable connection terminal are shown in the figure below.
