46
Step 7 Secure the junction box, fasten the buckle, and secure it with supplied M4×10 screw.
Step 8 Gently pull the cable backwards to ensure firm connection, and fasten the swivel nut
clockwise.
- - End
5.7 DC Cable Connection
The PV string will generate lethal high voltage when exposed to sunlight.
• Respect all safety instructions listed in relevant documents about PV strings.
5 Electrical Connection User Manual
