50
Step 3 Lead the cable through the cable gland, and insert the crimp contact into the insulator until it
snaps into place. Gently pull the cable backward to ensure firm connection. Tighten the ca-
ble gland and the insulator (torque 2.5 N.m to 3 N.m).
Step 4 Check for polarity correctness.
- - End
5 Electrical Connection User Manual
