119
Parameters SH5T SH6T
Topology (solar / battery) Transformerless / Transformerless
Degree of protection IP65
Dimensions (W x H x D) 620 * 480 * 195 mm
Weight 32kg
Mounting method Wall-mounting bracket
Operating ambient tempera-
ture range
-25 ℃ - 60 ℃
Allowable relative humidity
range(Non-condensing)
0% - 100%
Cooling method Natural convection
Max. operating altitude 2000m
Noise（Typical） 35dB(A)
Display LED
Communication
RS485, WLAN, Ethernet, CAN
DI / DO DI * 4 / DO * 2 / DRM0
DC connection type
MC4 ( PV, Max.6mm² ) / Plug and play connector ( bat-
tery, Max.10mm² )
AC connection type Plug and play connector ( Max.16mm² )
Country of manufacture China
* Depending on the connected battery.
** Can be reached only if PV and battery power is sufficient.
*** Only when the DC switch is set to "ON", the DC Type II is able to provide effective protec-
tion against electrical surges.
Note:The output voltage of strings should all exceed the lower limit of the full load MPPT
voltage range. The difference in string voltage between different MPPTs should be less than
150V.
Parameters SH8T SH10T
Input (DC)
Recommended max. PV in-
put power
16000 Wp 20000 Wp
Max. PV input voltage
1000 V
Min. PV input voltage / Start-
up input voltage
150 V / 180 V
Rated PV input voltage
600 V
MPP voltage range
150 V - 950 V
MPP voltage range for rated
power
355 V - 850 V 300 V - 850 V
User Manual 11 Appendix
