12. The thick black cable connects the sauna to the power source. Pass in
through and out the notch in the wall panel.
13. Connect the blue ethernet cable to the “CP” terminal on the same black
electrical box.
14. The connector with the red and black wires will be connected to the roof
lighting later. The white box is a circuit breaker for the sauna power.
15. Using the pre-drilled holes along the perimeter of the wall panels, screw the
walls to the ceiling panel.
16. After testing all electrical power and lights, it's time to place the roof panel
over the ceiling panel.
17. Plug The connector with the red and black wires into the connector wire
connector that's coming from the roof panel.
18. Using the “outside top wood” screws, attach the trim strips along the seam
between the wall panels and the roof, securing the roof to the entire
structure.
19. Make the last electrical connections for the heaters by plugging the black
cables by the floor into the outlets above them.
