APPENDIX C
DIAMETER RANGES
OF
MANDRELS & HONING UNITS
Fitting Pins in Pistons
SIZE RANGE
MANDREL inches millimeters
LH-370M .370 to .384 9,4 to 9,8
LH-432M .432 to .446 11,0 to 11,3
LJ-495M 495 to .525 12,6 to 13,3
LJ-526M .526 to .557 13,4 to 14,1
LJ-557M .557 to .587 14,1 to 14,9
LJ-619M .619 to .650 15,7 to 16,5
LJ-681M .681 to .713 17,3 to 18,1
3ML-750M .744 to .781 18,9 to 19,8
3ML-781M .775 to .812 19,7 to 20,6
3ML-812M .806 to .843 20,5 to 21,4
3ML-843M .838 to .875 21,3 to 22,2
3ML-87W 869 to .906 22,1 to 23,0
3ML-906M .900 to .937 22,9 to 23,8
3ML-937M .931 to .968 23,6 to 24,6
3ML-965M .962 to 1.000 24,4 to 25,4
3PL-1000M .990 to 1.062 25,1 to 27,0
3PL-1062M 1.052 to 1.125 26,7 to 28,6
3PL-1125M 1.115 to 1.187 28,3 to 30,1
3PL-1187M 1.177 to L250 29,9 to 31,7
3PL-1250M 1.230 to 1.375 31,2 to 34,9
3PL-1375M 1.355 to 1.500 34,4 to 38,1
3PL-1500M 1.480 to 1.625 37,6 to 41,3
3PL-1625M 1.605 to 1.750 40,8 to 4 4,4
3PL-1750M 1.730 to 1.875 43,9 to 47,6
3PL-1875M 1.851 to 2.000 47,1 to 50,8
3PL-2000M 1.980 to 2.125 50,3 to 54,0
3PL-2125M 2.105 to 2.250 53,5 to 57,1
3PL-2250M 2.230 to 2.375 56,0 to 60,3
3PL-2375M 2.355 to 2.500 59,8 to 63,5
3PL-2500M 2.480 to 2.625 63,0 to 66,7
King Pin Fitting
SIZE RANGE
MANDREL inches millimeters
3ML-625M .619 to .656 15,7 to 16,7
3ML-656M .650 to .687 16,5 to 17,4
3ML-687M .681 to .718 17,3 to 18,2
3ML-718M .711 to .750 18,1 to 19,0
4ML-718M .713 to .750 18,1 to 19,0
4ML-750M .744 to .781 18.9 to 19,8
4ML-781M .775 to .815 19,7 to 20,7
4ML-812M .806 to .843 20,5 to 21,4
4ML-843M .838 to .875 21,3 to 22,2
5ML-875M .869 to .906 22,1 to 23,0
5ML-906M .900 to .942 22,9 to 23,9
5ML-937M .931 to .968 23,6 to 24,6
5ML-968M .962 to 1.003 24,4 to 25,5
4PL-1031M 1.021 to 1.094 25,9 to 27,8
4PL-1094M 1.084 to 1.156 27,5 to 29,4
4PL-1125M 1.115 to 1.187 28,3 to 30,1
4PL-1219M 1.209 to 1.281 30,7 to 32,5
5PL-1312M 1.292 to 1.375 32,8 to 34,9
5PL-1375M 1.355 to 1.500 34,4 to 38,1
5PL-1562M 1.542 to 1.625 39,2 to 41,3
5PL-1625M 1.605 to 1.750 40,8 to 44,4
5PL-1750M 1.730 to 1.875 43,9 to 47,6
5PL-1875M 1.855 to 2.000 47,1 to 50,8
5PL-2000M 1.980 to 2.125 50,3 to 54,0
5PL-2125M 2.105 to 2.250 53,5 to 57,1
5PL-2250M 2.230 to 2.375 56,6 to 60,3
5PL-2375M 2.355 to 2.500 59,8 to 63,5
5PL-2500M 2.480 to 2.625 63,0 to 66,7
BUSHING EXPANDERS
EXPANDER SIZE RANGE
MANDREL inches millimeters
ALH-720 .720 to .840 18,3 to 21,3
ALH-840 .840 to .900 21,3 to 22,9
ALH-900 .900 to .960 22,9 to 24,4
ALH-960 .960 to 1.080 24,4 to 27,4
MANDRELS FOR PISTONS W/WIDE SLOTS
SIZE RANGE
MANDREL inches millimeters
RYY-875M .875 to .885 22,2 to 22,5
RYY-912M .912 to .922 23,2 to 23,4
SYY-927M .927 to .940 23,5 to 23,9
SYY-973M .975 to .980 24,8 to 24,9
SYY-989M .990 to 1.000 25,1 to 25,4
SYY-1040M 1.040 to 1.050 26,4 to 26,7
SYY-1094M 1.094 to 1.104 27,8 to 28,0
CAUTION: DO NOT ORDER FROM THIS PAGE. See
Sunnen
®
Engine Rebuilding Equipment Accessories
And Supplies Catalog
(A-7100) for complete ordering information.
