Installation-Assembly Procedures
Assembly Procedures
Hardware Inventory
Before you begin, use the utility knife to cut open the Hardware Box and remove
the small bag of hardware. In addition to a small allen wrench and pillow, make sure
you have the following hardware items.
Allen-Head Bolt 5/16" x 1" - Quantity 6
5/16" x 2" Bolt - Quantity 4
Pivot Stud Support - Quantity 2
5/16" Metal Washer - Quantity 6
Locking Nut - Quantity 2
Ball End - Quantity 2
Saucer Washer - Quantity 6
Plastic Cap - Quantity 6
Spacer - Quantity 4
Safety Goggles - Quantity 1
