Wide Awnings Split Option
Note: large awnings wider then 24' can be split into two, and is highly
recommended.
Fabrics on awnings that are greater than 24' wide might
sag and cause damage to the fabric and/or structure of the
awning. Therefore the fabric can be split in two sections with
an approx. 1" gap in-between. It will be on two roller tubes
connected with a center bracket providing extra support.
The front prole and valance will be one piece, controlled by
one gear/motor.
Installation process is the same as the regular awnings.
One front prole and one valance
One hood
One motor
and/or
manual gear
Approx.
1" gap
Two fabrics
Two roller tubes
Connected with a
center bracket
