18 3
PROTECTING THE SUNSETTER FABRIC
FROM MILDEW
If it is necessary to roll the awning up
wet, be sure to roll it out to dry when
the weather is better. While the vinyl
awning fabric itself won't mildew,
mildew can form on the dust and dirt
allowed to accumulate on the fabric. If
the fabric is rolled up and stored when
wet, the moisture will promote the
formation of mildew. Do not use caustic
cleaners.
CLEANING THE FABRIC
Cleaning the awning regularly will
extend the life of the fabric and prevent
the formation of mildew. Call 1-800-876-
2340 to order a SunSetter cleaning and
maintenance kit.
FOR EASE OF OPERATION
If it becomes difficult to raise and lower
the awning height, apply some of the
supplied wax to the small tracks on the
inside of the outer arms.
CAUTION: NEVER USE A BARBEQUE
GRILL (Figure 11), ANY TYPE OF PATIO
HEATER (Figure 12) OR FIREPLACE
(Figure 13) UNDER YOUR SUNSETTER
AWNING.
ENJOY YOUR AWNING!!!!
Figure 11
Figure 12
Figure 13
FIGURE 1
Using the hand crank, unroll the
awning until the front roller reaches
waist height.
FIGURE 2
Extend both arms until the front roller
reaches head height.
FIGURE 4
Adjust the roller bar position until the
arrow on the Roller Bar aligns with
the OPEN arrow on the side of the
Drive Unit.
FIGURE 5
Push both rafters 'UP' until they lock.
FIGURE 6
Extend both arms to the desired
height.
Both arms angled
(Recommended for stronger wind support)
OPEN:
FIGURE 3
Using the hand crank, unroll the
awning until the fabric is fully
extended.
OPEN Arrow
Roller Bar
Arrow
Drive Unit
To Next Page
