115
Pulse Motor –X and Y axis
If you lose X or Y movement, check for green lights on the X and Y boards.
NO. CORRECTIONMEANINGERROR MESSAGE
(+X) Frame Limit Detection
(–X) Frame Limit Detection
(+Y) Frame Limit Detection
(–Y) Frame Limit Detection
X Axis Driver Error
Y Axis Driver Error
Wiper Return Error
200
201
202
203
204
205
206
The frame has reached its +X
limit.
The frame has reached its –X
limit.
The frame has reached its +Y
limit.
The frame has reached its –Y
limit.
An error has occurred in the X
axis driver.
An error has occurred in the Y
axis driver.
Wiper Solenoid did not return.
Move the frame in the –X
direction
Move the frame in the +X
direction
Move the frame in the –Y
direction
Move the frame in the +Y
direction
Check for green light on front
of X axis board.
Check for green light on front
of Y axis board.
Repair Wiper Mechanism
To Next Page
