PART NO. 690809 REV: A 11
ITEM NO. QTY. PART NUMBER DESCRIPTION
1 1 942021 ASSEMBLY, FRAME, FL36
2 2 942022 ASSY, FLOATS, PREASSEMBLED, FL36
3 4 941955 ASSY, FLOAT BRACKET, FL24/36
4 2 942038 ASSY, FLOAT BRACKET, MI D, FL36
5 6 951419 WELDMENT, FLOAT BAND, FL24
6 4 941954 ASSY, CROSSBEAM EXTENSION, FL24/36
7 2 942023 ASSEMBLY, BUNK, FL36
8 4 442192 TUBE, GUIDE ON, RFL24
9 1 921814 ASSY, POWERPACK, FL24
10 1 911999 HARDWARE KIT, FL36
FL36/GFL36 Top Assembly
