PART NO. 690809 REV: A 17
Launching/retrieving.
Before Lifting/Launching/or retrieving, be sure to disconnect Powerpack from lift, secure and protect hoses and keep
hose quick disconnect fittings clean. Use caution when lifting Powerpack with fork lift to prevent damage.
Using Overhead Crane
With Frame and Floats fully assembled, and Powerpack disconnected, hoist with 4 straps/slings from the two end cross
beam tubes (5”x8”). For easier installation make sure all Float Control Pins are inserted and secure. Floats will rotate
downward upon lifting. If Float Control Pins in the Float Bracket are removed, the floats will rotate downward even
further making installation more difficult.
Installation
Lifting Slings can be secured around either
5”x 8” rectangular tube.
Be sure that slings don’t get pinched by
float arms and don’t interfere with operation
of the lift.
Float Control Pin,14-160026-88
Float Control Pins
