PART NO. 690809 REV: A 5
FL24/GFL24 Specification
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Boat lifting capacity: 24,000 lbs
Lifting speed: 85 to 100 sec (typ)
Lowering speed: 50 to 60 sec (typ)
Overall length: 38 ft 6 in
Overall width: 16 ft 1 in (up position)
20 ft 3 in (down position)
Min Slip width 22 ft
Min water depth: 5 ft
Max boat beam 13 ft 9 in
AC power required: 120VAC or 230VAC
AC charging output (High Amp Charger) 20 Amps at 24V
Weight: FloatLift structure without powerpack approx. 7900 lbs
FloatLift structure (without float assys) 3500 lbs
Float Assy (each side) 2200 lbs
Powerpack box (with sealed batteries) Approx. 445 lbs
Powerpack box (without batteries) Approx 200 lbs
Hose length: 35 ft
Structure: Alum 6061-T6 frame with stainless steel hardware
Floats: Rotomolded Polyethylene with expanded styrene foam
