4.7. Communication
4.7.1. Definition of Voltage Sampling Connector
PIN Wire No. Signal
Wire size (mm²）
Remarks
1 B0 Signal 0.3 Cell #1-
2 B2+ Signal 0.3 Cell #2+
3 B4+ Signal 0.3 Cell #4+
4 B6+ Signal 0.3 Cell #6+
5 B8+ Signal 0.3 Cell #8+
6 B10+ Signal 0.3 Cell #10+
7 B12+ Signal 0.3 Cell #12+
8 B14+ Signal 0.3 Cell #14+
9 B16+ Signal 0.3 Cell #16+
10 NC NC NC NC
11 B1+ Signal 0.3 Cell #1+
12 B3+ Signal 0.3 Cell #3+
13 B5+ Signal 0.3 Cell #5+
14 B7+ Signal 0.3 Cell #7+
15 B9+ Signal 0.3 Cell #9+
16 B11+ Signal 0.3 Cell #11+
17 B13+ Signal 0.3 Cell #13+
18 B15+ Signal 0.3 Cell #15+
4.7.2. Definition of Temp. Sampling Connector
PIN Wire No. Signal Wire size (mm²) Remarks
1 T1+ Signal 0.3 Temp. #1+
2 T2+ Signal 0.3 Temp. #2+
3 T3+ Signal 0.3 Temp. #3+
4 T4+ Signal 0.3 Temp. #4+
5 T1- Signal 0.3 Temp. #1-
6 T2- Signal 0.3 Temp. #2-
7 T3- Signal 0.3 Temp. #3-
8 T4- Signal 0.3 Temp. #4-
