PBM
1500
PBM
2000
PBM
2500
РBM
3000
PBM
5000
Capacity L 1500 2000 2500 3000 5000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 2140/2290 2131/2181 2713/2763 2746/2796 2841/2891
Minimalvercalclearance mm 2192 2220 2760 2817 2932
Diameterwithoutinsulaon/withinsulaon D,mm Ø1000/1200 Ø1200/1400 Ø1250/1450 Ø1400/1600 Ø1600/1800
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95 3/95 3/95
Recommendedboilersize,connectedto
buertank
kW 27-50 36-67 46-84 73-133 82-151
Weightwithoutinsulaon/withinsulaon kg,kgi 205/228 254/281 337/372 474/514 571/613
SleeveforElectricheangelement В,mm,Rp1
1/2
” 1260 1308 1678 1690 1754
Heatcarrier С1,mm,Rp1
1/2
” 339 388 396 438 502
Heatcarrier С2,mm,Rp1
1/2
” 339 388 396 438 502
Heatcarrier С3,mm,Rp1
1/2
” 833 848 1037 1064 1128
Heatcarrier С4,mm,Rp1
1/2
” 833 848 1037 1064 1128
Heatcarrier С5,mm,Rp1
1/2
” 1327 1308 1678 1690 1754
Heatcarrier С6,mm,Rp1
1/2
” 1327 1308 1678 1690 1754
Heatcarrier С7,mm,Rp1
1/2
” 1821 1768 2319 2316 2380
Heatcarrier С8,mm,Rp1
1/2
” 1821 1768 2319 2316 2380
Sensorsleeve А1,mm,Rp1/2” 339 388 396 438 502
Sensorsleeve А2,mm,Rp1/2” 833 848 1037 1064 1128
Sensorsleeve А3,mm,Rp1/2” 1327 1308 1678 1690 1754
Sensorsleeve А4,mm,Rp1/2” 1821 1768 2319 2316 2380
Airventsleeve F,mm,Rp1
1/2
” 2140 2131 2713 2746 2841
