Sunsystem PS Series - Page 22

22
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL
4.2.ModelРBMR-
with one coil
PBM R
300
PBM R
500
PBM R/H*
800
PBM R/H*
1000
Capacity L 300 500 800 1000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 1410/1460 1700/1750 1838/1888 2039/2089
Minimalvercalclearance mm 1430 1727 1877 2073
Diameterwithoutinsulaon/withinsulaon D,mm Ø550/750 Ø650/850 Ø790/990 Ø790/990
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95 3/95
Operangpressure/Max.coiltemperature bar/
0
C 16/110 16/110 16/110 16/110
Recommendedboilersize,connectedtobuertank kW 6-10 10-17 15-27 18-33
Weightwithoutinsulaon/withinsulaon kg,kgi 75/85 106/118 144/161 164/182
SleeveforElectricheangelement В,mm,Rp1
1/2
” 860 997 1090 1260
Heatcarrier С1,mm,Rp1
1/2
” 240 239 290 290
Heatcarrier С2,mm,Rp1
1/2
” 240 239 290 290
Heatcarrier С3,mm,Rp1
1/2
” 550 643 710 775
Heatcarrier С4,mm,Rp1
1/2
” 550 643 710 775
Heatcarrier С5,mm,Rp1
1/2
” 860 997 1090 1260
Heatcarrier С6,mm,Rp1
1/2
” 860 997 1090 1260
Heatcarrier С7,mm,Rp1
1/2
” 1170 1451 1750 1750
Heatcarrier С8,mm,Rp1
1/2
” 1170 1451 1750 1750
Sensorsleeve А1,mm,Rp1/2” 240 239 290 290
Sensorsleeve А2,mm,Rp1/2” 550 643 710 775
Sensorsleeve А3,mm,Rp1/2” 860 997 1090 1260
Sensorsleeve А4,mm,Rp1/2” 1170 1451 1750 1750
Airventsleeve F,mm,Rp1
1/2
” 1410 1700 2039 2039
CoilcapacityS1 S1L 5.6 9.8 14 15.2
HeatexchangesurfaceS1 S1m
2
0.9 1.6 2.3 2.48
Inlet/OutletLowercoilS1 S1i/S1o,mm,Rp1” 640/240 689/239 785/290 830/290
