SPBM
1000
SPBM
1500
SPBM
2000
Capacity L 1000 1500 2000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 2039/2089 2140/2290 2131/2181
Minimalvercalclearance mm 2073 2192 2220
Diameterwithoutinsulaon/withinsulaon D,mm Ø790/990 Ø1000/1200 Ø1200/1400
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95
Recommendedboilersize,connectedtobuertank kW 18-33 27-50 36-67
Weightwithoutinsulaon/withinsulaon kg,kgi 126/144 205/228 254/281
SleeveforElectricheangelement В,mm,Rp1
1/2
” 1260 1260 1308
Heatcarrier С1,mm,Rp1
1/2
” 290 339 388
Heatcarrier С2,mm,Rp1
1/2
” 290 339 388
Heatcarrier С3,mm,Rp1
1/2
” 775 833 848
Heatcarrier С4,mm,Rp1
1/2
” 775 833 848
Heatcarrier С5,mm,Rp1
1/2
” 1260 1327 1308
Heatcarrier С6,mm,Rp1
1/2
” 1260 1327 1308
Heatcarrier С7,mm,Rp1
1/2
” 1750 1821 1768
Heatcarrier С8,mm,Rp1
1/2
” 1750 1821 1768
Sensorsleeve А1,mm,Rp1/2” 290 339 388
Sensorsleeve А2,mm,Rp1/2” 775 833 848
Sensorsleeve А3,mm,Rp1/2” 1260 1327 1308
Sensorsleeve А4,mm,Rp1/2” 1750 1821 1768
Airventsleeve F,mm,Rp1
1/2
” 2039 2140 2131
