INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL
5.2.ModelSРBMR-
with one coil
SPBM R
300
SPBM R
500
SPBM R
800
Capacity L 300 500 800
Heightwithoutinsulaon/withinsulaon H,Hi,mm 1410/1460 1700/1750 1838/1888
Minimalvercalclearance mm 1430 1727 1877
Diameterwithoutinsulaon/withinsulaon D,mm Ø550/750 Ø650/850 Ø790/990
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95
Operangpressure/Max.coiltemperature bar/
0
C 16/110 16/110 16/110
Recommendedboilersize,connectedtobuertank kW 6-10 10-17 15-27
Weightwithoutinsulaon/withinsulaon kg,kgi 75/85 106/118 144/161
SleeveforElectricheangelement В,mm,Rp1
1/2
” 860 997 1090
Heatcarrier С1,mm,Rp1
1/2
” 240 239 290
Heatcarrier С2,mm,Rp1
1/2
” 240 239 290
Heatcarrier С3,mm,Rp1
1/2
” 550 643 710
Heatcarrier С4,mm,Rp1
1/2
” 550 643 710
Heatcarrier С5,mm,Rp1
1/2
” 860 997 1090
Heatcarrier С6,mm,Rp1
1/2
” 860 997 1090
Heatcarrier С7,mm,Rp1
1/2
” 1170 1451 1750
Heatcarrier С8,mm,Rp1
1/2
” 1170 1451 1750
Sensorsleeve А1,mm,Rp1/2” 240 239 290
Sensorsleeve А2,mm,Rp1/2” 550 643 710
Sensorsleeve А3,mm,Rp1/2” 860 997 1090
Sensorsleeve А4,mm,Rp1/2” 1170 1451 1750
Airventsleeve F,mm,Rp1
1/2
” 1410 1700 2039
CoilcapacityS1 S1L 5.6 9.8 14
HeatexchangesurfaceS1 S1m
2
0.9 1.6 2.3
Inlet/OutletLowercoilS1 S1i/S1o,mm,Rp1” 640/240 689/239 785/290
