7
Installation-Assembly Procedures
Attaching Canopy to Bench
Attach the canopy to the bench as shown below. This will require at least two
people.
1. Lift the canopy and hold it between the hinge brackets.
2. Insert the 5/16" x 1 1/2" bolts with the nylon washers into both hinge brackets.
Tighten bolts into the endcap threaded inserts until snug, then an additional half
turn. Do not overtighten to avoid damaging threaded inserts.
