Figure 2. Optical Indicators 2
Status Indicator Descriptions
Each element has its own LED STATUS indicator to show its operating status.
Figure 3. Status Indicator
Optical Indicator
Description
Green
Normal
Red
The optical path is not synchronized.
Blank
The Optical module is not plugged in
Status Indicator
Description
Flash Green
Element is working without an alarm
Solid Green
Software is crashed, but it will reboot automatically in 3 mins
Flash Red
Element is working but with alarm
Solid Red
Software is crashed (with alarm), but it will reboot automatically in 3 mins
Flash Orange
Software is upgrading
Solid Orange
Element is booting
