ORDER GUIDE
OPTIONS
Set of 10 housings and 30 connector pins
For installation to 35 mm 1.378 in width DIN rail
Vertical mounting bracket
Horizontal mounting bracket
Designation Model No. Description
Length: 2 m 6.562 ft
Length: 5 m 16.404 ft
0.2 mm
2
3-core cabtyre cable with connector
Cable outer diameter: "3.8 mm "0.150 in
Connector
Connector
attached cable
DIN rail
mounting bracket
Sensor mounting
bracket
Horizontal
multiple panel
mounting bracket
CN-63
CN-63-C2
CN-63-C5
MS-DP-2
MS-DP-3
MS-DP-4
MS-DP-5
1
2
3
Housing
Connector pin
1
2
3
Enables the sensors to be attached to each other laterally and mounted on
the panel.
Connector
• CN-63
Connector
attached cable
• CN-63-C2
• CN-63-C5
DIN rail mounting bracket
• MS-DP-2
Sensor mounting bracket
• MS-DP-3 • MS-DP-4
Label space
MS-DP-5
Panel fixing screw (Accessory)
Horizontal multiple panel mounting bracket
• MS-DP-5
m The above illustration
shows two units
connected in sequence.
Designed with a 9 mm 0.354 in label
space to enable the labeling of the sensors
with a label printer (9 mm 0.354 in width)
for sensor number and application data.
Accessory
• MS-DP-1 (Panel mounting bracket)
Type Appearance Rated pressure range (Note) Model No. Pressure port Output
Vacuum pressure
101 kPa
type
1 MPa type
100 kPa
type
Positive pressure
Compound pressure
0 to 101.3 kPa
0 to 1.000 MPa
100.0 to 100.0 kPa
DP4-50
DP4-50P
DP4-52
DP4-52P
DP4-57
DP4-57P
M5 female thread
NPN open-collector transistor
PNP open-collector transistor
NPN open-collector transistor
PNP open-collector transistor
NPN open-collector transistor
PNP open-collector transistor
Note: The rated pressure range indicates the range for full product performance.
