Supelco Spectroquant NOVA 60A - Maintenance Procedures; Changing the Lamp

Release 06/2019 17
Spectroquant
®
NOVA 60A - Operating Manual
– Set up the photometer again and connect it
to the power line
– Press and hold
– Switch on the meter (open the cover) and
after the following display appears, release
:
– Press
– Perform zero adjustment according to chap-
ter ZERO ADJUSTMENT.
Maintenance, cleaning, disposal
Maintenance - Changing the lamp
– Switch off the photometer and disconnect it
from the power line
– Carefully turn up the photometer and park it
safely
– Screw off the lamp cover on the underside of
the photometer
Let the lamp of the photometer
cool down.
– Pull out the plug
1
– Unscrew the screw
2
– Remove the lamp with its holder
3
by pull-
ing it gently upwards
Do not touch the new light bulb of
the photometer.
– Insert a new preset lamp and screw it tight
using the screw
2
– Connect the plug
1
– Screw the lamp cover on again
