Supelco Spectroquant NOVA 60A - Spectroquant NOVA 60 A Overview; Operating Elements Description; Connector Identification

Release 06/2019
6
Spectroquant
®
NOVA 60A - Operating Manual
Overview
Description of the operating elements
Identifying the connectors
1
Display
2
Menu call/Enter key
3
Scroll key
4
Absorbance measure-
ment key
5
Concentration measure-
ment key
6
Notch for cell alignment
7
Round cell shaft
8
Storage space for
analysis regulations
(short form)
9
Cover with integrated
on/o switch
10
Rectangular cell shaft
11
Keypad: numeric key-
pad, cursor function,
erase, comma
1
Power pack
2
Connection for power
pack
3
RS 232 interface
