Specifications
General
Frequency composition. PLL synthesizer
Frequency range. A 26.065 to 26.505 MHz
B 26.515 to 26.955 MHz
C 26.965 to 27.405 MHz
D 27.415 to 27.855 MHz
E 27.865 to 28.305 MHz
F 28.315 to 28.755 MHz
Channels. Total 3600: 240 5 MODE
240(+5 KHz) 5 MODE
240(- 5 KHz) 5 MODE
Frequency space. 10 to 20 KHz
Emission. AM/FM/USB/LSB/CW
Power source. 13.8 V DC (Only negative ground)
Receiver
Sensitivity. AM 1 micro-V @ 10 dB S/N
FM 1 micro-V @ 20 dB S/N
SSB/CW 0.5 micro-V @ 10 dB S/N
Selectivity. 60 dB
Audio Output. 2 W @ 8 Ohm
Fine Tune range. 800 Hz
Coarse Tune range.
Frequency. AM/FM 10.685 MHz/455 KHz
SSB/CW 10.695 MHz
Transmitter
RF power output. High Mid Low
SSB/CW (p-p) 12W 8W 2W
AM 7.5W 4W 1W
FM 10W 4W 1W
SSB generation. Double-balanced modulator with crystal
latice filter
Coarse Tune range. 5 khz
3
