Superior VRT3542WH - Product Specifications; Firebox Dimensions and Reference

NOTE:DIAGRAMS&ILLUSTRATIONARENOTTOSCALE.
10
Figure 8
SPECIFICATIONS
Gas Line
Access -
Both Sides
Access Opening for Junction
Box - Right Side Only
(remove the knock-out
before installing J-Box).
J-Box / Electrical Kit is not
provided with appliance.
Junction Box
Top View
A
E
C
D
P
*Q
F
H
J
M
N
1 (25)
7-1/16
(179)
Front View
B
G
Right Side View
L
K
Top Stand-Off
Spacers (4
places)
6-3/16
(157)
5-3/4
(146)
3-9/16
(90)
Top of Bottom
Refractory
Bottom of
Firebox
Opening
Top of Firebox
Opening
* Hood
Product Reference Information
Cat. No. Model Ship. Weight (lbs) Shipping Volume
F0322 VRT2536WS 150 lbs
20 Cu. Ft.
F0298 VRT3536WS 200 lbs
22 Cu. Ft.
F0299 VRT3536WH 200 lbs
22 Cu. Ft.
F0300 VRT3542WS 230 lbs
26 Cu. Ft.
F0301 VRT3542WH 230 lbs
26 Cu. Ft.
* A hood comes standard and is required for model VRT2536WS. The
factory-supplied hood must be installed on the firebox for safe opera-
tion for model VRT2536WS in all installations. This part is optional for
models VRT3536WS, VRT3536WH, VRT3542WS & VRT3542WH.
Dimensions - Inches (millimeters)
Model No. A B C D E F G H J K L M N P *Q
VRT2536WS
36
(914)
24
(610)
41-3/4
(1061)
37-1/4
(946)
23-1/2
(597)
20
(508)
3
(76)
7-3/8
(187)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
30-5/16
(770)
29-5/8
(753)
VRT3536WS &
VRT3536WH
36
(914)
28
(711)
41-3/4
(1061)
41-1/4
(1048)
23-1/2
(597)
20
(508)
3
(76)
8-3/8
(213)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
34-5/16
(872)
33-5/8
(854)
VRT3542WS &
VRT3542WH
42
(1067)
28
(711)
47-3/4
(1213)
41-1/4
(1048)
29-1/2
(749)
20
(508)
3
(76)
8-3/8
(213)
15-7/8
(403)
7-1/2
(190)
11-15/16
(303)
1-5/16
(33)
5-1/2
(140)
34-5/16
(872)
33-5/8
(854)
