FIREBOX FINISHES
Thereareawidevarietyof“nishedlooks”foryourbuilt-inVent-Freereboxfromformalwall
decor with elaborate mantels to rustic wood paneling or warm brick facings.
Onlynoncombustible materialslike marble,stone,tile, brick,etc. mayoverlapthe blackfront
facing.Sealalljointsbetweentheblackfacingandwallsurroundstopreventairintrusion.Use
noncombustible caulking material only to seal the black metal facing to the surround material on
thenishedwall.SeeFigures 3 & 26.
Raised Hearth Extension
Ahearthextensionmaybeusedbutisnotrequiredfortheseappliances.Araisedhearthextension
may be used as shown in Figure 26.
Raised Hearth Extension
(combustibles allowed.
No carpet or vinyl)
Combustible Platform
SIDE VIEW
Firebox Floor
Combustible Wall
Figure 26 - Raised Hearth Extension
Non-Combustible Wall
(see Figure 4)
Fireplace Opening
* From Base to
Bottom of Firebox
Opening (floor)
5-3/4" Max.*
Base
APPROVED ACCESSORIES AND
COMPONENTS
Decorative Volcanic Stone
The decorative volcanic stone, Model FDVS,
can be used to enhance the look of your ap-
pliance.OrdermodelFDVSforreplacement
of stone when needed. Spread the decorative
volcanic stone evenly around the bottom of
therebox.
JunctionBox/RecepticalKit
TheJunctionBox(J-Box)Kitisdesignedtobe
used whenan optionalFBK-100 or FBK-200
BlowerKitistobeinstalled.
(ref. Form #750010M)
Decorative Volcanic Stone
Cat. No. Model No. Description
80L42 FDVS Bag of Volcanic Stone
JunctionBox/RecepticalKit
Cat. No. Model No. Description
H1958 JBK
JunctionBox/ElectricalKit
(ref. Form #750203M)
DecorativeScreenDoorPanelKit
Cat. No. Model Where Used
H1959 ASD3624-TI VRT2536WS
H1960 ASD3628-TI VRT3536WS & VRT3536WH
H1961 ASD4228-TI VRT3542WS & VRT3542WH
DecorativeArchScreenPanelKit
This attractive screen door is easy to install and
enhances the appearance of the appliance.
(ref.Form#750209M)
