Chapter 2: Installation
2.4 Memory Support and Installation
Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to pre-
vent any possible damage.
Memory Support
The A2SDi-2C-HLN4F supports up to 128GB RDIMM or 32GB ECC/Non-ECC UDIMM DDR4
in two memory slots, two DIMM on single channel at up to 1866MT/s .
The A2SDi-4C-HLN4F support up to 256GB RDIMM or 64GB ECC/Non-ECC UDIMM DDR4
in four memory slots, two DIMM Per Channel (DPC) at up to 2133MT/s.
The A2SDi-8C/8C+/12C/16C-HLN4F support up to 256GB RDIMM or 64GB ECC/Non-ECC
UDIMM DDR4 in four memory slots, two DIMM Per Channel (DPC) at up to 2400MT/s.
Populating these DIMM slots with a pair of memory modules of the same type and size will
result in interleaved memory, which will improve memory performance.
Memory Population Guidelines
For optimal memory performance, follow the table below when populating memory. Populate
DIMM slots in the following order: DIMMA1, DIMMB1, then DIMMA2, DIMMB2
Unbuffered DDR4 ECC/Non-ECC DIMM Memory
DIMMs per
channel
DIMMs per
channel
DIMM Type POR Speed
MT/s
Memory Population
Sequence
1 1 Unbuffered
DDR4 DIMM
1866, 2133, 2400 A1, A2 (2 DIMMs)
2 2 Unbuffered
DDR4 DIMM
1866, 2133, 2400 A1, B1, A2, B2
(4 DIMMs)
Recommended Population (Balanced)
DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory
4GB 4GB 8GB
4GB 4GB 4GB 4GB 16GB
8GB 8GB 16GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 16GB 64GB
32GB 32GB 64GB
32GB 32GB 32GB 32GB 128GB
64GB 64GB 128GB
64GB 64GB 64GB 64GB 256GB
