Motherboard Features
CPU
• Intel® Atom SoC C3958/C3858/C3850 FCBGA1310 Processor
Memory
• Up to 64GB DDR4 ECC/Non-ECC Unbuffered SO-DIMM, two DPC (DIMM Per Channel) up to 2400MT/s
DIMM Size
• Up to 16GB at 1.2V
Expansion Slots
• One (1) PCI Express 3.0 x4
• One (1) Mini PCI Express x1
• One M.2 3.0 x4
Network
• Intel i350-AM4 Base-T NIC
• Intel X557-AT2 Base-T PHY
• CS4227 SFP+ PHY
BaseBoard Management Controller (BMC)
• ASpeed AST 2400 Baseboard Controller (BMC) supports IPMI 2.0
• One (1) Dedicated IPMI LAN port located on the rear IO back panel
Graphics
• Graphics controller via ASpeed 2400 BMC
I/O Devices
• Serial (COM) Port
• SATA 3.0 Ports
• One (1) serial header
• Four (4) SATA 3.0 ports (I-SAT0 ~ I-SATA3) I-SATA0 is SuperDOM
Peripheral Devices
• Two (2) USB 3.0 ports on the rear I/O panel (USB0/1)
• Two (2) internal USB 2.0 headers with two (2) USB connections each for front access (USB2/3, USB4/5)
BIOS
• 128 Mb SPI AMI BIOS
®
SM Flash UEFI BIOS
• ACPI 4.0, USB keyboard, Plug-and-Play (PnP), SPI quad speed support, Riser card auto detection support, RTC (Real
Time Clock) wakeup, Dual Boot Block support, and SMBIOS 2.7
Motherboard Features
To Next Page
