Super A2SDi-TP8F/LN4F, A2SDi-16C-TP8F User's Manual
88
When SEL is Full
This feature allows the user to determine what the BIOS should do when the system event
log is full. Select Erase Immediately to erase all events in the log when the system event
log is full. The options are Do Nothing and Erase Immediately.
Note: After making changes on a setting, be sure to reboot the system for the changes
to take effect.
BMC Network Conguration
The following items will be displayed:
IPMI LAN Selection
This feature displays the IPMI LAN setting. The default setting is Failover.
IPMI Network Link Status
This feature displays the IPMI Network Link status. The default setting is Dedicated LAN.
Update IPMI LAN Conguration
Select Yes for the BIOS to implement all IP/MAC address changes at the next system boot.
The options are No and Yes.
*If the feature above is set to Yes, the Conguration Address Source and VLAN
features are available for conguration:
Conguration Address Source
Use this feature to select the source of the IP address for this computer. If Static is selected,
you will need to know the IP address of this computer and enter it to the system manually in
the eld. If DHCP is selected, the BIOS will search for a DHCP (Dynamic Host Conguration
Protocol) server in the network that is attached to and request the next available IP address
for this computer. The options are DHCP and Static.
The following items are assigned IP addresses automatically if DHCP is selected, or they
can be congured manually if Static is selected.
Station IP Address
This feature displays the Station IP address for this computer. This should be in decimal
and in dotted quad form (i.e., 192.168.10.253).
Subnet Mask
This feature displays the sub-network that this computer belongs to. The value of each
three-digit number separated by dots should not exceed 255.
