Supermicro AOC-CTGS-i2T - LED Indicators

Chapter 2: Hardware Components
2-3
2-4 LED Indicators
GLAN Port LEDs
Two LAN ports (LAN 1/LAN 2) are
located on the add-on card. Each
Ethernet LAN port has two LEDs. The
green LED on the left indicates activity;
while the other LED on the right may
be green, amber or O󰀨 to indicate the
speeds of the connections. See the ta-
bles on the right for more information.
LAN 1/LAN 2 Link LED (Right)
LED State
LED Color Denition
Green 10 Gbps
Amber 1 Gbps
O󰀨 100 Mbps or No Con-
nection
LAN 1/LAN 2 Activity LED (Left)
LED State
Color Status Denition
Amber Flashing Active
Activity LED
LAN Ports
Pin Denition
Pin# Denition
1 M_MDI0_P0
2 M_MDI0_N0
3 M_MDI0_P1 9 LINK0_10G
6 M_MDI0_N1 10 LINK0_1G
4 M_MDI0_P2 11 LINK0_LINKUP
5 M_MDI0_N2 12 LINK0_ACT_N
7 M_MDI0_P3 13 GND
8 M_MDI0_N3 14 GND
IPMI LAN
(X8ST3-F)
Link LED
