AOC-CTGS-i2T Add-on Card User's Guide
Conventions Used in the User's Guide
Pay special attention to the following symbols for proper system installation and to
prevent damage to the system or injury to yourself:
Warning: Important information given to ensure proper system installation
or to prevent damage to the components or injury to yourself.
Note: Additional information given to di󰀨erentiate between various models
or provides information for correct system setup.
Naming Convention
SMC Networking Add-on Cards
Confidential
Naming Convention for Networking Adapters
A O C – S T G N – i 2 S
1 – 2 3 4 – 5 6 7
Character Representation Options
1st Product Family AOC: Add On Card
2nd Form Factor S: Standard, P: Proprietary, C: MicroLP, U: UIO
3rd Product Type/Speed G: GbE (1Gb/s), TG: 10GbE (10Gb/s), 40G: 40GbE
(40Gb/s), IBF: FDR IB (56Gb/s), IBQ: QDR IB (40Gb/s)
4th Chipset Model (Optional) N: Niantec (82599), P: Powerville (i350),
S: Sageville (X550)
5th Chipset Manufacturer i: Intel, m: Mellanox, b: Broadcom
6th Number of Ports 1: 1 port, 2: 2 ports, 4: 4 ports
7th Connector Type (Optional) S: SFP+, T: 10GBase-T, Q: QSFP+
Model Type Form Factor Controller Connection
Dimension
(w/o Brackets) (L x H)
Power
(W)
AOC-MGP-i2 GbE SIOM Intel® i350 AM2 2 RJ45 (1Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 3.7
AOC-MGP-i4 GbE SIOM Intel® i350 AM4 4 RJ45 (1Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 4.4
AOC-MTGN-i2S 10GbE SIOM Intel® 82599ES 2 SFP+ (10Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 7.2
AOC-MTG-i4S 10GbE SIOM Intel® XL710-BM1 4 SFP+ (10Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 7
AOC-MTG-b2T 10GbE SIOM Broadcom® BCM57416 2 RJ45 (10GBase-T) 3.622" (92mm) x 3.428" (87.08mm) 11
AOC-MTG-i2T 10GbE SIOM Intel® X550-AT2 2 RJ45 (10GBase-T) 3.622" (92mm) x 3.428" (87.08mm) 13
AOC-MTG-i4T 10GbE SIOM 2x Intel® X550-AT2 4 RJ45 (10GBase-T) 3.622" (92mm) x 3.428" (87.08mm) 26
AOC-MHIBF-m1Q2G
FDR IB
GbE
SIOM
Mellanox® ConnectX-3 Pro
Intel® i350
1 QSFP (56Gb/port)
2 RJ45 (1Gb/port)
3.622" (92mm) x 3.428" (87.08mm) 9
AOC-MHIBF-m2Q2G
FDR IB
GbE
SIOM
Mellanox® ConnectX-3 Pro
Intel® i350
2 QSFP (56Gb/port)
2 RJ45 (1Gb/port)
3.622" (92mm) x 3.428" (87.08mm) 11
AOC-MHIBE-m1CG
EDR IB
GbE
SIOM
Mellanox® ConnectX-4 VPI
Intel® i210
1 QSFP28 (100Gb/port)
1 RJ45 (1Gb/port)
3.622" (92mm) x 3.428" (87.08mm) 19
AOC-MH25G-b2S2G 25GbE SIOM
Broadcom® BCM57414
Intel® i350
2 SFP28 (25Gb/port)
2 RJ45 (1Gb/port)
3.622" (92mm) x 3.428" (87.08mm) 9
AOC-MH25G-m2S2T 25GbE SIOM
Mellanox® ConnectX-4 Lx EN
Intel® X550-AT2
2 SFP28 (25Gb/port)
2 RJ45 (10GBase-T)
3.622" (92mm) x 3.428" (87.08mm) 25
AOC-M25G-m4S 25GbE SIOM Mellanox® ConnectX-4 Lx EN 4 SFP28 (25Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 20
AOC-M25G-i2S 25GbE SIOM Intel® XXV710 2 SFP28 (25Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 11.8
AOC-MHFI-i1C
Omni-
Path
SIOM
Intel® OP HFI ASIC
(Wolf River WFR-B)
1 QSFP28 (100Gb/port) 3.622" (92mm) x 3.428" (87.08mm) 15
