SuperServer E50-9AP-N5 User's Manual
Chapter 3
Motherboard Connections

             
on the motherboard are also described here. A motherboard layout indicating component
locations can be found in Chapter 1.
Review the Safety Precautions in Appendix B before installing or removing components.
3.1 Ports
LAN Ports
Two LAN ports (JLAN1 - JLAN2) are located on the I/O back panel. These ports accept RJ45
type cables. Refer to the LED Indicator section for LAN LED information. Refer to the table

LAN Port
Pin Denition
Pin# Denition Pin# Denition
1 GND 9 TRD1+
2 CT_VCC 10 TRD1-
3 TRD4+ 11 GRN+/ORG-
4 TRD4- 12 GRN-/ORG+
5 TRD3+ 13 YEL+
6 TRD3- 14 YEL-
7 TRD2+ 15 SH1
8 TRD2- 16 SH2
