SuperServer E50-9AP-N5 User's Manual
3.2 LED Indicators
LAN Port LEDs
There are two LAN ports (JLAN1 and JLAN2) on the I/O back panel of the motherboard. Each
Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED
󰀨
LAN1/2 LED
(Connection Speed
Indicator)
LED Color Denition
󰀨 10 Mb/s
Green 100 Mb/s
Amber 1 Gb/s
Power LED
LED1 is the Power LED. In S0 mode, this LED will be solid green. In S3/S4/S5 modes, this
LED will be solid red.
Onboard Power LED Indicator
LED Color Denition
󰀨
󰀨
(power cable not
connected)
Solid Green S0 mode
Solid Red S3/S4/S5 modes
