28
SuperServer E50-9AP-N5 User's Manual
Functions
SATA
PCI Express
USB
LPC
SMBus
DDI
Power
Misc
GND
JEIO1
This Supermicro I/O header provides support for the following functions: DP/HDMI, two PCIe
x1, two USB 2.0, LPC, SATA, SMBus, and Power.
Supermicro EI/O
Pin Denition
Pin# Denition Pin# Denition
1 PCIE_EIO_RX_DP0 61
GND
2 PCIE_EIO_TX_DP0
3 PCIE_EIO_RX_DN0 4 PCIE_EIO_TX_DN0
5 GND 6 GND
7 PCIE_EIO_RX_DP1 8 PCIE_EIO_TX_DP1
9 PCIE_EIO_RX_DN1 10 PCIE_EIO_TX_DN0
11 GND 12 GND
13 CLK_100M_EIO_DP 14 USB_P5_DP
15 CLK_100M_EIO_DN 16 USB_P5_DN
17 GND 62
GND
18 USB_P4_DP
19 DDI1_TXP2 20 USB_P4_DN
21 DDI1_TXN2 22 GND
23 GND 24 DDI1_TXP3
25 DDI1_TXP1 26 DDI1_TXN3
27 DDI1_TXN1 28 GND
29 GND 30 DDI_HPD
31 DDI1_TXP0 32 SOC_WAKE_EIO_N
33 DDI1_TXN0 63
GND
34 DDI1_DDC_P1V8_
DAT
35 GND 36 DDI1_DDC_P1V8_
CLK
37 DDI1_AUXP 38 SOC_SMB_CLK
39 DDI1_AUXN 40 SOC_SMB_DAT
41 P5VSB 42 P3VSB
43 P5VSB 44 LPC_LFRAME_N
45 P12VSB 46 LPC_AD3
47 SOC_LPC_CLKOUT1 64
GND
48 LPC_AD2
49 PLTR_
TPM_80PORT_N
50 LPC_AD1
51 LPC_SERIRQ 52 LPC_AD0
53 P3V3 54 P5V
55 PS_ON_N 56 GND
57 EIO_SATA_TXP0 58 EIO_SATA_RXN0
59 EIO_SATA_TXN0 60 EIO_SATA_RXP0
