30
SuperServer E50-9AP-N5 User's Manual
System Management Bus Header and SATA Power
A System Management Bus header for additional slave devices or sensors is located at
JSMBUS1 on the bottom side of the motherboard. This header also serves as a 5V SATA

SMBus Header
Pin Denition
Pin# Denition
1 SMB_CLK
2 SMB_DATA
3 GND
4 P5V
