SuperServer E50-9AP-N5 User's Manual
Reset Button
The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to a hardware reset

Reset Button
Pin Denition (JF1)

3 Reset
4 Ground
Power LED
The Power LED connection is located on pins 7 and 8 of JF1. Refer to the table below for

Power LED
Pin Denition (JF1)

7 +3.3VSB
8 Power LED LOW
HDD LED
The HDD LED connection is located on pins 5 and 6 of JF1. Attach a cable here to indicate
the status of HDD-related activities, including SATA activities. Refer to the table below for

HDD LED
Pin Denition (JF1)

5 +3.3V
6 HDD Active LOW
