Chapter 1: Overview
1-5
X10DRL-i Jumpers
Jumper
Description Default Setting
JBT1 Clear Onboard CMOS Battery See Chapter 2
JI
2
C1/ JI
2
C2 SMB to PCI-E Slots Pins 2-3 (Disabled)
JPB1 BMC Enable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1/JPL2 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
X10DRL-i Connectors
Connectors Description
BT1 Onboard CMOS Battery (See Chpt. 3 for Used Battery Dis-
posal)
COM1/COM2 Back_panel COM Port1/Front Accessible COM2 Header
Fan1-6, FanA/B CPU/System Fan Headers
J24 24-pin ATX Main Power Connector (See Warning on Pg.
1-6.)
JD1 Speaker/Power LED
JF1 Front Panel Control Header
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPWR1/JPWR2 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JSD1 SATA DOM (Device on Module) Power Connector
JSTBY1 Standby Power Connector
JTPM1 TPM (Trusted Platform Module)/Port 80 Header
JUIDB1 UID (Unit Identication) Button
LAN1/LAN2 G-bit Ethernet (GLAN) Ports 1/2
IPMI_LAN IPMI_Dedicated LAN support by the Aspeed Controller
I-SATA 0-5 SATA 3.0 Connectors supported by Intel PCH (I-SATA 0-5)
S-SATA 0-3 SATA 3.0 Connectors supported by Intel SCU (S-SATA 0-3)
(PCH) Slot1 PCI-Express 2.0 x4 in x8 Slot from Intel PCH
(CPU1) Slot2 PCI-Express 3.0 x8 Slot from CPU1
(CPU1) Slot3 PCI-Express 3.0 x8 Slot from CPU1
(CPU2) Slot4 PCI-Express 3.0 x4 in x8 Slot from CPU2
(CPU1) Slot5 PCI-Express 3.0 x16 Slot from CPU1
(CPU1) Slot6 PCI-Express 3.0 x8 Slot from CPU1
