Supermicro X10DRL-i SUPERO User Manual

1-6
X10DRL-i Motherboard User’s Manual
Warning!
To avoid damaging the power supply or the motherboard, be sure to use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect the
power supply to the 24-pin power connector (J24), and two 8-pin power connectors
(JPWR1, JPWR2) on the motherboard. Failure in doing so may void the manufacturer
warranty on your power supply and motherboard.
I-SGPIO1/2 Seria_Link General Purpose I/O Headers 1/2 (I-SGPIO1
for I-SATA0-3, I-SGPIO2 for I-SATA4/5)
S-SGPIO Seria_Link General Purpose I/O Header (for S-SATA0-3)
SP1 Internal Speaker/Buzzer
(BP) USB 0/1 Backpanel USB 2.0 Ports 0/1
(BP) USB 12/13 (3.0) Backpanel USB 3.0 Ports 12/13
(FP) USB 2/3 Front-Accessible USB 2.0 Connection Header 2/3
(FP) USB 4 Front-Accessible Type A Connector USB 2.0 Port 4
(FP) USB 8/9 (3.0) Front-Accessible USB 3.0 Connection Header 8/9
VGA Backpanel VGA Port
X10DRL-i LED Indicators
LED Description State Status
LE1 Rear UID LED Blue: On Unit Identied
LE2 Onboard PWR LED On System Power On
LEDM1 BMC Heartbeat LED Green: Blinking BMC Normal

Supermicro X10DRL-i SUPERO Specifications

General

Form Factor	ATX
Chipset	Intel C612
Integrated Graphics	ASPEED AST2400
Socket	LGA 2011-3
Memory Support	DDR4 ECC RDIMM and LRDIMM
Memory Slots	8 DIMM slots
Storage	10 SATA3 (6Gbps)
USB Ports	4x USB 3.0 ports (2 rear, 2 via header) 6x USB 2.0 ports (2 rear, 4 via header)
RAID Support	RAID 0, 1, 5, 10
IPMI	Yes, with dedicated LAN port
BIOS	AMI BIOS
Networking	Dual Gigabit Ethernet LAN ports (Intel i210)
