Supermicro X13DAI-T User Manual

12
Super X13DAI-T User's Manual
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Port Enable/Disable Pins 1-2 (Enabled)
JPTG1 10GbE LAN Port Enable/Disable Pins 1-2 (Enabled)
JTP1 TPM Module Mode Pins 1-2 (Onboard TPM Module Enabled)
JVRM1 VRM SMBus Clock (to BMC or PCH) Pins 1-2 (BMC, Normal)
JVRM2 VRM SMBus Data (to BMC or PCH) Pins 1-2 (BMC, Normal)
LED Description Status
LED4 M.2-C1 LED Blinking Green: Device Working
LED7 M.2-C2 LED Blinking Green: Device Working
LEDBMC1 BMC Heartbeat LED
Blinking Green: BMC Normal (Active)
Solid Green: During BMC Reset or during a Cold Reboot
LEDPWR1 Power LED LED On: Onboard Power On
Connector Description
AUDIO FP Front Panel Audio Header
BT1 Onboard CMOS Battery
COM1 Front Accessible COM Header
FAN1 – FAN10,
FANA, FANB, FANC
FAN1 – FAN10: CPU Fan Headers
FANA, FANB, FANC: System Fan Headers
I-SATA8, I-SATA9
SATA 3.0 Connectors with support of SuperDOM devices
* DOM: Disk on Module
JAUDIO1 Rear I/O Audio Ports
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I
2
C Header
JL1 Chassis Intrusion Header
JNCSI1 Network Controller Sideband Interface (NC-SI) Connector
JNVI2C1
NVMe SMBus I
2
C Header used for PCIe SMBus clock and data connections with hot-plug
support
JPI2C1
Power SMBus I
2
C Header used for monitoring the power supply, fans, and system
temperatures
JPWR1 24-pin ATX Main Power Supply Connector
JPWR2, JPWR3,
JPWR4
8-pin Power Connectors
JRK1 Intel VROC Key Header for NVMe RAID support
JS1 (SATA0~7)
SlimSAS LP Connector with support of eight Intel PCH SATA 3.0 connections (Supports
RAID 0, RAID 1, RAID 5, and RAID 10)
Note: For details on how to congure Network Interface Card (NIC) settings, please
refer to the Network Interface Card Conguration User's Guide posted on our website
under the link: https://www.supermicro.com/support/manuals/.
