Chapter 1: Introduction
Connector Description
JSD1, JSD2 SATA DOM Power Connectors
JTPM1 Trusted Platform Module/Port 80 Header
LAN1, LAN2 Rear I/O 10GbE LAN Ports (LAN1: shared BMC LAN port)
M.2-C1, M.2-C2 PCIe 5.0 NVMe M.2 Slots (with support of M-Key 2280 and 22110)
P1 SLOT1/3/5 PCIe 5.0 x16 Slots supported by CPU1
P2 SLOT2/4 PCIe 5.0 x16 Slots supported by CPU2
P2 SLOT6 PCIe 5.0 x8 Slot supported by CPU2
P1_NVME0/1 NVMe PCIe 5.0 x8 MCIO Connector supported by CPU1 with two NVMe connections
P2_NVME0/1 NVMe PCIe 5.0 x8 MCIO Connector supported by CPU2 with two NVMe connections
T-SGPIO1 Serial General Purpose I/O Header
USB0/1 Front-accessible USB 2.0 Header
USB2/3/4/5 Rear I/O USB 3.0 Ports
USB6/7 Front-accessible USB 3.0 Header
USB8 Internal USB 3.1 Gen 2 Connector
VGA Rear I/O VGA port
